Electrical Driven Single stage and 2 Stage Dry Vacuum Pumps
Producing a vacuum for modern industrial applications requires a method of air removal
that is simple, dependable and economical to operate and maintain. All of these
requirements are met by the Ingersoll Rand T30 air-cooled reciprocating single-stage and
two-stage vacuum pumps.
Free Air Delivery cfm At
Working Pressure (35.1 kg/cm²g)
251 Package
5
6.45
7T2 Package
10-12.5
21.60
15T2 Package
20
37.70
15T2 Duplex Package
40
75.40
For high pressure operation, adequate care must
be taken for proper selection. Our distributors
would be happy to assist you in correct
selection of model. Models are also available
for higher working pressures upto 351 kg/cm² g.
Details available on request.
These pumps achieve vacuum upto 737mm (29.0"
Hg) for single stage and upto 754.4mm (29.7"
Hg) for two stage configuration, at sea
level.
These dry type vacuum pumps are ideal for
paper handling, food processing, vacuum
forming, liquid transfer and many other
applications.
