Electrical Driven 2 stage T-30 series High pressure compressor
Ingersoll Rand multi-stage high-pressure air compressors are designed for high-pressure applications. These compressors have extra heavy-duty components and are designed for minimum maintenance and maximum performance. High-pressure air compressors are widely used in power generation plant, PET blow molding industry, military, diving and component testing.
Durable cast-iron with two, three and four stage design.
Intermediate duty applications.
Extended pump life for years of trouble-free service.
V - sheave (compressor pulley).
Dry type intake filter.
Air cooled inter-stage cooler with condensate drain leg.
Inter-stage pressure gauge.
Inter-stage safety valve.
Air-cooled after-cooler.
Model Specifications
Technical Data
Model
Nominal Power kW (hp)
Max Pressure barg (psig)
FAD L/min (CFM)
L x W x H MM (IN)
Weight KG (LB)
231X30
2.2 (3)
35 (500)
140 (4.9)
867 x 515 x 510 (34 x 20 x 20)
100 (220)
7T4X55
4 (5.5)
70 (1000)
180 (6.4)
1219 x 720 x 813 (48 x 28 x 32)
240 (529)
7T4X55 LOL
4 (5.5)
70 (1000)
180 (6.4)
1219 x 720 x 813 (48 x 28 x 32)
240 (529)
7T2X100 S/D
8.5 (12)
35 (500)
630 (22.2)
1238 x 670 x 840 (49 x 26 x 33)
275 (606)
15T2X200-35
15 (20)
35 (500)
1120 (39.5)
1432 x 840 x 868 (56 x 33 x 34)
406 (895)
15T2X200-35 S/D
15 (20)
35 (500)
1120 (39.5)
1432 x 840 x 868 (56 x 33 x 34)
406 (895)
15T2X200-35 S/D LOL
15 (20)
35 (500)
1120 (39.5)
1432 x 840 x 868 (56 x 33 x 34)
406 (895)
15T2X200-35 S/D LOL Auto Drain
15 (20)
35 (500)
1120 (39.5)
1432 x 840 x 868 (56 x 33 x 34)
406 (895)
15T2X200-70
15 (20)
70 (1000)
920 (32.5)
1432 x 840 x 868 (56 x 33 x 34)
415 (915)
15T2X200-70 S/D LOL
15 (20)
70 (1000)
920 (32.5)
1432 x 840 x 868 (56 x 33 x 34)
415 (915)
High Pressure Receiver Mounted Package
Model
Motor HP
Free Air Delivery cfm At Working Pressure (35.1 kg/cm²g)
251 Package
5
6.45
7T2 Package
10-12.5
21.60
15T2 Package
20
37.70
15T2 Duplex Package
40
75.40
For high pressure operation, adequate care must be taken for proper selection. Our distributors would be happy to assist you in correct selection of model. Models are also available for higher working pressures upto 351 kg/cm² g. Details available on request.
